Aluminum foil tapes are widely used in HVAC and refrigerator industry. They are also suitable for sealing joints and seams of foil-faced insulation materials, such as flexible ducts and connections.
1, Aluminum Foil Tapes with Rubber-resin Adhesive
2, Aluminum Foil Tapes with Solvent Acrylic Adhesive
PRODUCT FORM & SIZE AVAILABLE
Cut Roll: 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4")
Log Roll: 1200mm x 45 / 50m Jumbo Roll: 1200mm x 1000m / 1200m / 1350m
IMPORTANT NOTE
1. The data above are typical values only, and should not be used for specifications purpose.
2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Cut Roll: ±0.3m, Jumbo Roll ±0.5%.
STORAGE & SHELF LIFE: 12 months when stored at 21°C (70°F) / 50% relative humidity out of direct sunlight.
SURFACE PREPARATION: It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied must be clean, dry, free of grease, oil or other contaminants.
PRODUCT USE: It is essential that the user evaluate the product to determine whether it is fit for a particular purpose and user's method of application. Good results will be obtained when applied to a clean, dry surface with a suitable pressure on products between -10 ~ +40°C (+50 ~ +105 °F).
1, Aluminum Foil Tapes with Rubber-resin Adhesive
| Aluminum foil tapes are widely used in HVAC and refrigerator industry. They are also suitable for sealing joints and seams of foil-faced insulation materials, such as flexible ducts and connections. 1, Aluminum Foil Tapes with Rubber-resin Adhesive
2, Aluminum Foil Tapes with Solvent Acrylic Adhesive
PRODUCT FORM & SIZE AVAILABLE Cut Roll: 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4") Log Roll: 1200mm x 45 / 50m Jumbo Roll: 1200mm x 1000m / 1200m / 1350m IMPORTANT NOTE 1. The data above are typical values only, and should not be used for specifications purpose. 2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Cut Roll: ±0.3m, Jumbo Roll ±0.5%. STORAGE & SHELF LIFE: 12 months when stored at 21°C (70°F) / 50% relative humidity out of direct sunlight. SURFACE PREPARATION: It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied must be clean, dry, free of grease, oil or other contaminants. PRODUCT USE: It is essential that the user evaluate the product to determine whether it is fit for a particular purpose and user's method of application. Good results will be obtained when applied to a clean, dry surface with a suitable pressure on products between -10 ~ +40°C (+50 ~ +105 °F).  | ||||||||||||||||||||||||||||||||||||||||||||||||||
2, Aluminum Foil Tapes with Solvent Acrylic Adhesive
| Product | Description | Application |
| AF25A | Foil: 25u / Solvent Acrylic Adhesive / Silicone Release Paper | Commercial grade foil tape. Suitable for sealing joints and seams of foil-faced insulation materials. |
| AF30A | Foil: 30u / Solvent Acrylic Adhesive / Silicone Release Paper | High-grade foil tape. Good for sealing joints and seams of foil-faced insulation materials. |
| AF40A | Foil: 40u / Solvent Acrylic Adhesive / Silicone Release Paper | High-grade foil tape. Excellent for sealing joints and seams of foil-faced insulation materials. Good for refrigerator industry, metal patching and sound dampening applications. |
| AF50A | Foil: 50u / Solvent Acrylic Adhesive / Silicone Release Paper | High-grade foil tape. Excellent for sealing joints and seams of FSK-faced insulation materials. Good for refrigerator industry, metal patching and sound dampening applications. |
| AF75A | Foil: 75u / Solvent Acrylic Adhesive / Silicone Release Paper | Premium grade foil tape. Excellent protection for masking operations in electroplating and paint stripping. |
| AF7150A | 3-way Foil-Scrim-Kraft / Solvent Acrylic Adhesive / Silicone Release Paper | High-grade FSK Tape, 3-way scrim. Sealing joints and seams of 3-way Foil-Scrim-Kraft faced insulation. |
| AF1801A | Alum Glass Cloth backing / Solvent Acrylic Adhesive / Silicone Release Paper | High-grade foil tape. Excellent for sealing joints and seams of insulation materials. |
PRODUCT FORM & SIZE AVAILABLE
Cut Roll: 48 / 50mm (2") / 60 / 63mm (2.5") / 72 / 75mm (3") / 96mm / 100mm (4")
Log Roll: 1200mm x 45 / 50m Jumbo Roll: 1200mm x 1000m / 1200m / 1350m
IMPORTANT NOTE
1. The data above are typical values only, and should not be used for specifications purpose.
2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Cut Roll: ±0.3m, Jumbo Roll ±0.5%.
STORAGE & SHELF LIFE: 12 months when stored at 21°C (70°F) / 50% relative humidity out of direct sunlight.
SURFACE PREPARATION: It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied must be clean, dry, free of grease, oil or other contaminants.
PRODUCT USE: It is essential that the user evaluate the product to determine whether it is fit for a particular purpose and user's method of application. Good results will be obtained when applied to a clean, dry surface with a suitable pressure on products between -10 ~ +40°C (+50 ~ +105 °F).
